Metal oxydatum Zinc High Voltage Surge Arrester for Overhead Line

Zinc oxydatum impetus comprehensor est fulgurum fabrica cum praesidio superiori tutelae peractae, leve pondus, pollutio resistentiae et effectus stabilis.Maxime bonis non linearibus volt-ampere notis zinci zinci utitur ut currentem per aestum comprehensorem fluens faciat ad voltationem perparvam operationem normalem (microamp vel milliampere campestri);quando involutionis agit, resistentia acriter cadit, energia ad effectum tutelae obtinendum arcebat.Differentia inter hoc genus fulminis comprehensor et traditor comprehensor fulminis est quod hiatum non habet, et notis non linearibus utitur spodi cadmiae ad solvendum et frangendum.

Availability:



Inquire Addere ad cartallum

depictio producti

Surge Arrester Series

Generalis

1. Ratings: 0.22~500KV (porcelain), 0.22~220KV(compositum)

2. Applicatio: ad tutelam potentiae transmissionis & distributionis systematis e nimia intentione.

3. Features:

1）Silicone polymer habitationem compositam metalli oxydatum salo comprehensorem et fictilem habitationem metalli oxydorum fluctuum comprehensores praesto sunt.

2° Facilis institutionem et sustentationem.

3） Facultas obsignandi bonum ad certam operationem obtinendam.

4） Praesidio et firmitas comprehensoris aestus vehementer aucta sunt.

_副本

Opus Condition

1. Ambiens temperies aeris: -40℃ ~+40℃ ;

2. Altitude：<=2000m;

3. Frequentia: 48Hz~62Hz;

4. Potestas frequentia intentione applicata inter terminales chirurgiae comprehensor non debet excedere intentionem continuam operantem surgentis arretricis;

5. Terrae motus intensio est minor quam 8 gradus;

6. Maximilianus.Ventus celeritas est 35m/s.

Techical Parameter principalis

1. Metal oxydatum Polymerus Praesent (Gapless) type Surge Arrester pro AC System (5kA series)

Exemplar	Ratum intentione (kVr.ms)	Continua operating intentione (KVr.ms）	Levatio motus residua voltage sub nominis missione current (<=KVp)	Linea missio classis	Spatium Creepage (mm)	2ms quadratum fluctus impetus current resistit (A)	4/10μhigh vena impetus sustinet (KAp)
YH-5W-6	6	5.1	18		320	150	65
YH-5W-9	9	7.65	27		430	150	65
YH-5W-12	12	10.2	36		430	150	65
YH-5W-15	15	12.75	45		530	150	65
YH-5W-18	18	15.3	54		530	150	65
YH-5W-21	21	16.8	63		640	150	65
YH-5W-24	24	19.2	72		640	150	65
YH-5W-27	27	21.6	81		740	150	65
YH-5W-30	30	24	90		890	150	65
YH-5W-33	33	26.4	99		890	150	65
YH-5W-36	36	28.8	108		1115	150	65

2. Metal oxydatum Polymerus Praesent (Gapless) type Surge Arrester pro AC System (10KA series)

Exemplar	Ratum intentione (kVr.ms)	Continua operating intentione (KVr.ms）	Levatio motus residua voltage sub nominis missione current (<=KVp)	Linea missio classis	Spatium Creepage (mm)	2ms quadratum fluctus impetus current resistit (A)	4/10μhigh vena impetus sustinet (KAp)
YH-10W-6	6	5.1	18	1	320	250	100
YH-10W-9	9	7.65	27	1	430	250	100
YH-10W-12	12	10.2	36	1	430	250	100
YH-10W-15	15	12.75	45	1	530	250	100
YH-10W-18	18	15.3	54	1	530	250	100
YH-10W-21	21	16.8	63	1	640	250	100
YH-10W-24	24	19.2	72	1	740	250	100
YH-10W-27	27	21.6	81	1	740	250	100
YH-10W-30	30	24	90	1	890	250	100
YH-10W-33	33	26.4	99	1	890	250	100
YH-10W-36	36	28.8	108	1	1115	250	100
YH-10W-42	42	33.6	126	2	1260	400	100
YH-10W-48	48	39	139	2	1260	400	100
YH-10W-54	54	42	160	2	1260	400	100
YH-10W-60	60	48	178	2	1465	400	100
YH-10W-66	66	52.8	196	2	1465	400	100
YH-10W-72	72	57	214	2	2255	400	100
YH-10W-84	84	67.2	244	2	2255	400	100
YH-10W-90	90	72.5	249	2	2255	400	100
YH-10W-96	96	75	265	3	3555	800	100
YH-10W-108	108	84	281	3	3555	800	100
YH-10W-120	120	96	300	3	4153	800	100
YH-10W-150	150	120	416	3	5040	800	100
YH-10W-200	200	156	520	3	7110	800	100

3. Metal oxydatum Polymerus Praesent (Gapless) type Surge Arrester pro AC System (20KA series)

Exemplar	Ratum intentione (kVr.ms)	Continua operating intentione (KVr.ms）	Levatio motus residua voltage sub nominis missione current (<=KVp)	Linea missio classis	Spatium Creepage (mm)	2ms quadratum fluctus impetus current resistit (A)	4/10μhigh vena impetus sustinet (KAp)
YH-20W-108	108	84	281	3	3555	800	100
YH-20W-120	120	96	300	3	4153	800	100
YH-20W-150	150	120	416	3	5040	800	100
YH-20W-200	200	156	520	3	7110	800	100

4. Metallum Oxide Porcelain Praesent (Gapless) type Surge Arrester pro AC System (5KA series)

Exemplar	Ratum intentione (kVr.ms)	Continua operating intentione (KVr.ms）	Levatio motus residua voltage sub nominis missione current (<=KVp)	Linea missio classis	Spatium Creepage (mm)	2ms quadratum fluctus impetus current resistit (A)	4/10μhigh vena impetus sustinet (KAp)
Y5W-6	6	5.1	18		280	150	65
Y5W-9	9	7.65	27		320	150	65
Y5W-12	12	10.2	36		320	150	65
Y5W-15	15	12.75	45		450	150	65
Y5W-18	18	15.3	54		450	150	65
Y5W-21	21	16.8	63		450	150	65
Y5W-24	24	19.2	72		510	150	65
Y5W-27	27	21.6	81		510	150	65
Y5W-30	30	24	90		890	150	65
Y5W-33	33	26.4	99		890	150	65
Y5W-36	36	28.8	108		890	150	65
