Insulatores late utuntur in lineae transmissionis supra caput ad sustentationem mechanicam et tutelam electricam, nec non in lineas et substationes distribuendas.Silicone Flexilis est maxime late usui polymericae materia pro altae voltage insulatoribus. HAIVO notam compositam insulator e silicone rubber. Secundum intentiones considerationes, varia genera insulatorum in systematis potentiae adhibentur, nos Pin insulator, iactator insulator, suspensio insulator. post insulator, longus virga insulator, insulator horizontalis, insulator ferriviarius, dica insulator, mane insulator.
leve, indissolubile, hydrophobic, repugnant ozone UV radiorum, resistens terrae motus
Long virga suspensionis insulator? Compositum insulators ad altum voltage caput potentia tradenda linea application
Pro aestimata intentione usque ad 550 kV lineas transmissionis potentiae sustinentes, suspendentes et velit.
Rating: Usque ad 500kV.
Signa: IEC 61109
Compositum Insulator pro AC Power Distribution System
Features: Secura et certa operatio in altis vi mechanica.Foedus consilium et leve in pondere quod ad vecturam opportunum est.Bonae facultatem anti-vibrationis.anti- umoris bonam facultatem.Bonum electricum spectacula Fortis anti-pollutionis falsoveri facultatem.Princeps anti-canus spectacula quae perfecta est ad utendum sub condicione altae altitudinis.Facilis ad victum.
Product range:
Longa virga composita insulatores usque ad 500kV.
Compositum insulator pin usque ad 36kV.
Post composita insulator usque ad 252kV.
Linea post composita insulator usque ad 36kV.
1) Silicone Flexilis habitationum formata per totam iniectionem hydrophobicitatem, drophobicitatem migrationis et soli resistentiam habet, necnon optimae roperties electricae et resistentiae senescentes, quae efficaciter impedire possint accidentia pollutionis lampadoris ita ut cursus tutus altae curet. lineae intentione tradenda.
2) In fibreglass ECR mutationis aucti epoxy resinae virgae adhibita est, quae bonam habet repugnantiam ad caliditatem, accentus corrosionem & impetum acidum, tum denique actionem debilitans, vires altae distrahentes (>1200Mpa) et resistentia ad serpendum et lassitudinem deficiendi, quae efficaciter curare velit internam qualitatem et vires mechanicas insulatorum.
3) Caerimoniae in fibreglass virgae clauduntur cum obsessio generis crimper voce operata, Insulatores cum hac technica arte critica altam vim mechanicam et parvam dissipationem habent.
4) Connexio locationis inter caerimonias & virgas connexio cum vineis habitationem diffunditur ab altiore alta tempera- tura vulcanizata silicone globulus injectionis corona, prout potuit interfaciem obscurare.
5) Interna multi- sigilli radialis structura efficaciter praestat longum tempus firmitatem sigilli circum nexum inter caerimonias & virgas.
Nota:
1 Lorem starand:IEC,ANSI,GB et alia signa internationalia
2 Color ordinarius compositi insulatoris: rubri, cinerei et albi.
3 Consilium speciale secundum exigentiam emptoris.
| Pelagus Technical Parameter | |||||||
| Model | SpecifiMechanica onus ed (KN) | Spatio H (mm) | Arcing spatium (>mm)) | Minimum Creepage procul | Fulmen impulsum resiste voltage (>= KVp) | Infectum potentiae frequentiae intentionem sustinere (>=KVr.ms) | Factory exemplar |
| CS70XZ-100/465 | 70 | 360 | 215 | 480 | 100 | 50 | FXBW-15/70 |
| CS120XZ-100/465 | 120 | 400 | 215 | 480 | 100 | 50 | FXBW-15/120 |
| CS70XZ-120/450 | 70 | 413 | 275 | 544 | 120 | 60 | FXBW-17.5/70 |
| CS120XZ-120/450 | 120 | 513 | 275 | 544 | 120 | 60 | FXBW-17.5/120 |
| CS70XZ-125/480 | 70 | 461 | 320 | 550 | 125 | 70 | FXBW-24/70(20mm/ KV) |
| CS120XZ-125/480 | 120 | 490 | 320 | 550 | 125 | 70 | FXBW- 24/120(20mm/KV) |
| CS70XZ-145/745 | 70 | 500 | 355 | 750 | 145 | 80 | FXBW-24/70(31mm/ KV) |
| CS120XZ-145/745 | 120 | 529 | 355 | 750 | 145 | 80 | FXBW- 24/120(31mm/KV) |
| CS70XZ-185/900 | 70 | 541 | 400 | 900 | 185 | 95 | FXBW-36/70 |
| CS120XZ-185/900 | 120 | 570 | 400 | 900 | 185 | 95 | FXBW-36/70 |
| CS70XZ-230/1120 | 70 | 610 | 455 | 1250 | 230 | 105 | FXBW-36/70(31mm/ KV) |
| CS120XZ-230/1120 | 120 | 650 | 455 | 1250 | 230 | 105 | FXBW- 36/120(31mm/KV) |
| CS70XZ-325/1815 | 70 | 860 | 710 | 2210 | 325 | 150 | FXBW-72.5/70 |
| CS120XZ-325/1815 | 120 | 900 | 710 | 2210 | 325 | 150 | FXBW-72.5/120 |
| CS70XZ-550/3150 | 70 | 1220 | 1055 | 3400 | 550 | 230 | FXBW-126/70 |
| CS120XZ-550/3150 | 120 | 1255 | 1055 | 3400 | 550 | 230 | FXBW-126/120 |
| CS120XZ-650/3625 | 120 | 1475 | 1270 | 4100 | 650 | 275 | FXBW-145/70 |
| CS210XZ-650/3625 | 160 | 1654 | 1485 | 4495 | 650 | 250 | FXBW-145/160 |
| CS120XZ-1050/6300 | 210 | 2550 | 2300 | 8500 | 1050 | 460 | FXBW-245/210 |
| CS160XZ-1050/6300 | 160 | 2430 | 2200 | 7000 | 1050 | 400 | FXBW-252/160 |
| CS120XZ-1425/9075 | 120 | 3180 | 2780 | 9880 | 1425 | 570 | FXBW-363/120 |
| CS210XZ-1425/9075 | 210 | 3440 | 3000 | 10450 | 1425 | 570 | FXBW-363/210 |
| CS120XZ-2250/13750 | 120 | 4450 | 4050 | 14100 | 2250 | 740 | FXBW-550/120 |
| CS210XZ-2250/13750 | 210 | 4450 | 4050 | 13850 | 2250 | 740 | FXBW-550/210 |
