33kv Silicone Purgamentum compositum Insulator pro Support cable
domum » Products » composita Insulator » 33kv Silicone Purgamentum compositum Insulator pro Support cable

loading

ut Share:
sharethis sharing button

33kv Silicone Purgamentum compositum Insulator pro Support cable

Insulatores late utuntur in lineae transmissionis supra caput ad sustentationem mechanicam et tutelam electricam, nec non in lineas et substationes distribuendas.Silicone Flexilis est maxime late usui polymericae materia pro altae voltage insulatoribus. HAIVO notam compositam insulator e silicone rubber. Secundum intentiones considerationes, varia genera insulatorum in systematis potentiae adhibentur, nos Pin insulator, iactator insulator, suspensio insulator. post insulator, longus virga insulator, insulator horizontalis, insulator ferriviarius, dica insulator, mane insulator.

Availability:

Virga longa insulator suspensionis;

leve, indissolubile, hydrophobic, repugnant ozone UV radiorum, resistens terrae motus

Long virga suspensionis insulator? Compositum insulators ad altum voltage caput potentia tradenda linea application

Pro aestimata intentione usque ad 550 kV lineas transmissionis potentiae sustinentes, suspendentes et velit.


Rating: Usque ad 500kV.


Signa: IEC 61109


Compositum Insulator pro AC Power Distribution System


Features: Secura et certa operatio in altis vi mechanica.Foedus consilium et leve in pondere quod ad vecturam opportunum est.Bonae facultatem anti-vibrationis.anti- umoris bonam facultatem.Bonum electricum spectacula Fortis anti-pollutionis falsoveri facultatem.Princeps anti-canus spectacula quae perfecta est ad utendum sub condicione altae altitudinis.Facilis ad victum.


Product range:

Longa virga composita insulatores usque ad 500kV.

Compositum insulator pin usque ad 36kV.

Post composita insulator usque ad 252kV.

Linea post composita insulator usque ad 36kV.


Notae Technologiae:

1) Silicone Flexilis habitationum formata per totam iniectionem hydrophobicitatem, drophobicitatem migrationis et soli resistentiam habet, necnon optimae roperties electricae et resistentiae senescentes, quae efficaciter impedire possint accidentia pollutionis lampadoris ita ut cursus tutus altae curet. lineae intentione tradenda.

2) In fibreglass ECR mutationis aucti epoxy resinae virgae adhibita est, quae bonam habet repugnantiam ad caliditatem, accentus corrosionem & impetum acidum, tum denique actionem debilitans, vires altae distrahentes (>1200Mpa) et resistentia ad serpendum et lassitudinem deficiendi, quae efficaciter curare velit internam qualitatem et vires mechanicas insulatorum.

3) Caerimoniae in fibreglass virgae clauduntur cum obsessio generis crimper voce operata, Insulatores cum hac technica arte critica altam vim mechanicam et parvam dissipationem habent.

4) Connexio locationis inter caerimonias & virgas connexio cum vineis habitationem diffunditur ab altiore alta tempera- tura vulcanizata silicone globulus injectionis corona, prout potuit interfaciem obscurare.

5) Interna multi- sigilli radialis structura efficaciter praestat longum tempus firmitatem sigilli circum nexum inter caerimonias & virgas.


Nota:

1 Lorem starand:IEC,ANSI,GB et alia signa internationalia

2 Color ordinarius compositi insulatoris: rubri, cinerei et albi.

3 Consilium speciale secundum exigentiam emptoris.


Pelagus Technical Parameter
Model SpeciMechanica onus ed (KN) Spatio H (mm) Arcing spatium (>mm)) Minimum Creepage procul Fulmen impulsum resiste voltage (>= KVp) Infectum potentiae frequentiae intentionem sustinere (>=KVr.ms) Factory exemplar
CS70XZ-100/465 70 360 215 480 100 50 FXBW-15/70
CS120XZ-100/465 120 400 215 480 100 50 FXBW-15/120
CS70XZ-120/450 70 413 275 544 120 60 FXBW-17.5/70
CS120XZ-120/450 120 513 275 544 120 60 FXBW-17.5/120
CS70XZ-125/480 70 461 320 550 125 70 FXBW-24/70(20mm/
KV)
CS120XZ-125/480 120 490 320 550 125 70 FXBW-
24/120(20mm/KV)
CS70XZ-145/745 70 500 355 750 145 80 FXBW-24/70(31mm/
KV)
CS120XZ-145/745 120 529 355 750 145 80 FXBW-
24/120(31mm/KV)
CS70XZ-185/900 70 541 400 900 185 95 FXBW-36/70
CS120XZ-185/900 120 570 400 900 185 95 FXBW-36/70
CS70XZ-230/1120 70 610 455 1250 230 105 FXBW-36/70(31mm/
KV)
CS120XZ-230/1120 120 650 455 1250 230 105 FXBW-
36/120(31mm/KV)
CS70XZ-325/1815 70 860 710 2210 325 150 FXBW-72.5/70
CS120XZ-325/1815 120 900 710 2210 325 150 FXBW-72.5/120
CS70XZ-550/3150 70 1220 1055 3400 550 230 FXBW-126/70
CS120XZ-550/3150 120 1255 1055 3400 550 230 FXBW-126/120
CS120XZ-650/3625 120 1475 1270 4100 650 275 FXBW-145/70
CS210XZ-650/3625 160 1654 1485 4495 650 250 FXBW-145/160
CS120XZ-1050/6300 210 2550 2300 8500 1050 460 FXBW-245/210
CS160XZ-1050/6300 160 2430 2200 7000 1050 400 FXBW-252/160
CS120XZ-1425/9075 120 3180 2780 9880 1425 570 FXBW-363/120
CS210XZ-1425/9075 210 3440 3000 10450 1425 570 FXBW-363/210
CS120XZ-2250/13750 120 4450 4050 14100 2250 740 FXBW-550/120
CS210XZ-2250/13750 210 4450 4050 13850 2250 740 FXBW-550/210
